Factory Provide Telescopic Multi Stage Hydraulic Cylinder for Trailer, Truck, Agricultural Machines

Introducing, the Junfu Hydraulic’s Telescopic Multi Stage Hydraulic Cylinder, the perfect solution for your trailer, truck, and agricultural machine needs. This top-of-the-line hydraulic cylinder is manufactured by a reputable factory, ensuring quality and durability that you can rely on.

Designed to provide maximum stability and performance, this hydraulic cylinder features multiple stages that allow for precise control and flexibility in various applications. Whether you are lifting heavy loads on a trailer, transporting goods with a truck, or operating agricultural machinery, the Junfu Hydraulic’s Cylinder is the ideal choice for enhancing efficiency and productivity.

Constructed with high-grade materials and expert craftsmanship, this hydraulic cylinder is built to last. Its telescopic design allows for easy adjustment to different heights and positions, making it versatile for a wide range of tasks. With a strong hydraulic system, you can expect smooth and reliable operation every time.

The Junfu Hydraulic’s Telescopic Multi Stage Hydraulic Cylinder is designed to meet the highest standards of quality and performance. It undergoes rigorous testing to ensure that it meets all safety and reliability requirements, giving you peace of mind when using it in demanding work environments.

In addition to its superior performance, this hydraulic cylinder is also user-friendly and easy to maintain. With proper care and regular inspections, you can prolong its lifespan and avoid costly repairs down the road. Its compact design and convenient installation make it a hassle-free addition to your equipment.

Whether you are a professional contractor, farmer, or warehouse operator, the Junfu Hydraulic’s Telescopic Multi Stage Hydraulic Cylinder is the perfect choice for your hydraulic needs. With its durable construction, reliable performance, and user-friendly design, this hydraulic cylinder is sure to exceed your expectations and help you get the job done efficiently.

Upgrade your equipment with the Junfu Hydraulic’s Telescopic Multi Stage Hydraulic Cylinder and experience the difference in quality and performance. Trust in Junfu hydraulic for all your hydraulic cylinder needs

Description	Pressure - bar	Tipping weight - ton	Weight - kg	Volume - l	Max thrust 1 st stage - ton	G - mm	I - mm	K - mm	S - mm
ULE077-2-0410-K135-40-½“-HC	190	6-10	13	1.8	8	420	240	135	245
ULE 077-2-0610-K135-40-½“-HC	190	6-9	16	2.7	8	502	340	135	343
ULE 077-2-0770-K135-40-½“-HC	190	6-9	18	3.4	8	582	420	135	423
ULE 077-3-0745-K130-40-½“-HC	190	4-9	17	2.7	8	435	280	130	284
ULE 077-3-0925-K130-40-½“-HC	190	3-9	20	3.3	8	495	340	130	343
ULE 077-3-1045-K130-40-½“-HC	190	3-9	22	3.7	8	535	380	130	383

Our Advantages

1. Safer Junfu hydraulic cylinder adopts excellent structural design and new material application, which can withstand the harshest working conditions and continue to work stably without disconnection, ensuring the safety of drivers and vehicles, and creating the most valuable safety for users
2. faster unloading
Junfu series oil cylinder adopts excellent structural design to improve the unloading speed of the oil cylinder
3. higher lift frequency
Junfu series oil cylinders are suitable for all-weather short barge and high-frequency operations, with stable performance, extremely low failure rate, increasing the number of transfers and reducing downtime
4. Greater adaptability to the environment
Junfu series oil cylinder adopts innovative sealing technology and new material application, which can adapt to the temperature range of -40~110ºC, and can achieve excellent performance in high temperature and low temperature environment operation
5. lighter
Compared with other products of the same series, Junfu series cylinders reduce the dead weight by 15%~20%, and increase the lifting force by 10%~15%
6. Greater lifting force
Compared with other products of the same series, the lifting force of junfu series cylinders is increased by 10%~15%. More lift, more load, more profit! Lighter dead weight, greater lifting force, more lightness

Well Quality Management system

1. Trial Operation Test

2. Start-up Pressure Test

3. Pressure-Tight Test

4. Leak Test

5. Full Stroke Test

6. Buffer Test

7. Testing the Effect of Limit

8. Load Efficiency Test

9. Reliability Test
Every piece hydraulic cylinder will be tested before deliver

Our customer

FAQ

Q1: How about the quality
One year warranty, full life service

Q2: What's your cylinder's advantages
The cylinders are manufactured by advanced equipments and made under strictly quality control processing
The steel is tempered and all raw materials are good quality from world famous companies
Competitive price

Q3: When your company be established
Our company be established in 2002, professional manufacturer of hydraulic cylinders more than 20 years
We had passed IATF 16949:2016 Quality control system, ISO9001, CE

Q4: How about the delivery time
30 days approximately
